| Model No. | HMA-MB1000 | HMA-MB1500 | HMA-MB2000 |
| Rated Capacity (standard condition) |
60～80t/h | 100～120t/h | 140～160t/h |
| Rated Mixer Volume | 1000 kg | 1500 kg | 2000 kg |
| Drum Size diameter×length |
Ø1.5m×6.6m | Ø1.8m×8m | Ø1.9m×9m |
| Mixture Asphalt Aggregate Ratio | 3%～9% | ||
| Filler Proportion | 4%～10% | ||
| Finished Product Output Temperature | 150～180 ℃ | ||
| Fuel/Coal Consumption | ≤6.5kg/t（10～12kg/t） | ||
| Aggregate Filler Weighing Accuracy | ±0.5% (static weighing), ±2.5% (dynamic weighing) | ||
| Asphalt Weighing Accuracy | ±0.25% (static weighing), ±2.0% (dynamic weighing) | ||
| Finished Product Output Temperature Stability | ±5℃ | ||
| Dust Emission | ≤50mg/Nm³ (bag filter) | ||
| Ambient Noise | ≤85 dB(A) | ||
| Noise at Operation Station | ≤70 dB(A) | ||
